Motor ABB 3GBP seri 3GJP181410-A_H Profesional IP55 3 Fase Motor Listrik

Nama merek:	ABB
Nomor Model:	M2QA QABP QAEJ; MQAEJ M2QA

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Place of Origin:

China

Fitur Lindungi:

Tahan air, IP55

Tegangan AC:

380v

Fase:

Saat ini:

2.4A

Torsi keluaran:

200Nm

Kelas Isolasi:

Lampiran:

NEMA

Kekuatan motor:

0,06–1119 KW

Menyoroti:

3GBP seri 3 Fase Motor Listrik

IP55 Motor Listrik 3 Fase

Mesin listrik 3 fase profesional

Deskripsi Produk

Deskripsi Produk:

ABB menawarkan rangkaian motor tegangan rendah, termasuk seri M2QA, seri M2BAF, seri M2BAX, seri M3AA, seri M3BP, seri QAMT, seri QABP, seri M2JAX, dan seri M3JP.

kekuatan	model	Jumlah tiang	Metode instalasi: B3 Nomor pesanan	Metode instalasi: B5 Nomor pesanan
3000 putaran/menit = 2 kutub
0,75	M3JP80MA	2	3GJP081310-A_H	3GJP081310-B_H
1.1	M3JP80MB	2	3GJP081320-A_H	3GJP081320-B_H
1.5	M3JP90SLA	2	3GJP091010-A_H	3GJP091010-B_H
2.2	M3JP90SLC	2	3GJP091030-A_H	3GJP091030-B_H
3	M3JP100LA	2	3GJP101510-A_H	3GJP101510-B_H
4	M3JP112MB	2	3GJP111320-A_H	3GJP111320-B_H
5.5	M3JP132SMB	2	3GJP131220-A_H	3GJP131220-B_H
7.5	M3JP132SMD	2	3GJP131240-A_H	3GJP131240-B_H
11	M3JP160MLA	2	3GJP161410-A_H	3GJP161410-B_H
15	M3JP160MLB	2	3GJP161420-A_H	3GJP161420-B_H
18.5	M3JP160MLC	2	3GJP161430-A_H	3GJP161430-B_H
22	M3JP180MLA	2	3GJP181410-A_H	3GJP181410-B_H
30	M3JP200MLA	2	3GJP201410-A_G	3GJP201410-B_G
37	M3JP200MLC	2	3GJP201430-A_G	3GJP201430-B_G
45	M3JP225SMB	2	3GJP221220-A_G	3GJP221220-B_G
55	M3JP250SMA	2	3GJP251210-A_G	3GJP251210-B_G
75	M3JP280SMA	2	3GJP281210-A_G	3GJP281210-B_G
90	M3JP280SMB	2	3GJP281220-A_G	3GJP281220-B_G
110	M3JP315SMA	2	3GJP311210-A_G	3GJP311210-B_G
132	M3JP315SMB	2	3GJP311220-A_G	3GJP311220-B_G
160	M3JP315SMC	2	3GJP311230-A_G	3GJP311230-B_G
200	M3JP315MLA	2	3GJP311410-A_G	3GJP311410-B_G
250	M3JP355SMA	2	3GJP351210-A_G	3GJP351210-B_G
315	M3JP355SMB	2	3GJP351220-A_G	3GJP351220-B_G
355	M3JP355SMC	2	3GJP351230-A_G	3GJP351230-B_G
400	M3JP355MLA	2	3GJP351410-A_G	3GJP351410-B_G
450	M3JP355MLB	2	3GJP351420-A_G	3GJP351420-B_G
500	M3JP355LKA	2	3GJP351810-A_G	3GJP351810-B_G
560	M3JP400LA	2	3GJP401510-A_G	3GJP401510-B_G
560	M3JP400LKA	2	3GJP401810-A_G	3GJP401810-B_G
630	M3JP400LB	2	3GJP401520-A_G	3GJP401520-B_G
630	M3JP400LKB	2	3GJP401820-A_G	3GJP401820-B_G
710	M3JP400LC	2	3GJP401530-A_G	3GJP401530-B_G
710	M3JP400LKC	2	3GJP401830-A_G	3GJP401830-B_G
3000 putaran/menit = 2 kutub
9.2	M3JP132SME	2	3GJP131250-A_H	3GJP131250-B_H
22	M3JP160MLD	2	3GJP161440-A_H	3GJP161440-B_H
30	M3JP180MLB	2	3GJP181420-A_H	3GJP181420-B_H
37	M3JP180MLC	2	3GJP181430-A_H	3GJP181430-B_H
45	M3JP200MLE	2	3GJP201450-A_G	3GJP201450-B_G
55	M3JP225SMC	2	3GJP221230-A_G	3GJP221230-B_G
67	M3JP225SMD	2	3GJP221240-A_G	3GJP221240-B_G
75	M3JP250SMB	2	3GJP251220-A_G	3GJP251220-B_G
90	M3JP250SMC	2	3GJP251230-A_G	3GJP251230-B_G
110	M3JP280SMC	2	3GJP281230-A_G	3GJP281230-B_G
1) Kelas efisiensi IE1
1500 putaran/menit = 4 kutub
0,55	M3JP80MA	4	3GJP082310-A_H	3GJP082310-B_H
0,75	M3JP80MB	4	3GJP082320-A_H	3GJP082320-B_H
1.1	M3JP90SLA	4	3GJP092010-A_H	3GJP092010-B_H
1.5	M3JP90SLC	4	3GJP092030-A_H	3GJP092030-B_H
3	M3JP100LB	4	3GJP102520-A_H	3GJP102520-B_H
4	M3JP112MC	4	3GJP112330-A_H	3GJP112330-B_H
5.5	M3JP132SMB	4	3GJP132220-A_H	3GJP132220-B_H
7.5	M3JP132SMD	4	3GJP132240-A_H	3GJP132240-B_H
11	M3JP160MLC	4	3GJP162430-A_H	3GJP162430-B_H
15	M3JP160MLE	4	3GJP162450-A_H	3GJP162450-B_H
18.5	M3JP180MLA	4	3GJP182410-A_H	3GJP182410-B_H
30	M3JP200MLB	4	3GJP202420-A_G	3GJP202420-B_G
37	M3JP225SMB	4	3GJP222220-A_G	3GJP222220-B_G
45	M3JP225SMC	4	3GJP222230-A_G	3GJP222230-B_G
55	M3JP250SMA	4	3GJP252210-A_G	3GJP252210-B_G
75	M3JP280SMA	4	3GJP282210-A_G	3GJP282210-B_G
90	M3JP280SMB	4	3GJP282220-A_G	3GJP282220-B_G
110	M3JP315SMA	4	3GJP312210-A_G	3GJP312210-B_G
132	M3JP315SMB	4	3GJP312220-A_G	3GJP312220-B_G
160	M3JP315SMC	4	3GJP312230-A_G	3GJP312230-B_G
200	M3JP315MLA	4	3GJP312410-A_G	3GJP312410-B_G
250	M3JP355SMA	4	3GJP352210-A_G	3GJP352210-B_G
315	M3JP355SMB	4	3GJP352220-A_G	3GJP352220-B_G
355	M3JP355SMC	4	3GJP352230-A_G	3GJP352230-B_G
400	M3JP355MLA	4	3GJP352410-A_G	3GJP352410-B_G
450	M3JP355MLB	4	3GJP352420-A_G	3GJP352420-B_G
500	M3JP355LKA	4	3GJP352810-A_G	3GJP352810-B_G
560	M3JP400LKA	4	3GJP402810-A_G	3GJP402810-B_G
560	M3JP400LA	4	3GJP402510-A_G	3GJP402510-B_G
630	M3JP400LKB	4	3GJP402820-A_G	3GJP402820-B_G
630	M3JP400LB	4	3GJP402520-A_G	3GJP402520-B_G
710	M3JP400LKC	4	3GJP402830-A_G	3GJP402830-B_G
710	M3JP400LC	4	3GJP402530-A_G	3GJP402530-B_G
1500 putaran/menit = 4 kutub
9.2	M3JP132SME	4	3GJP132250-A_H	3GJP132250-B_H
18.5	M3JP160MLF	4	3GJP162460-A_H	3GJP162460-B_H
22	M3JP160MLG	4	3GJP162470-A_H	3GJP162470-B_H
30	M3JP180MLC	4	3GJP182430-A_H	3GJP182430-B_H
37	M3JP200MLC	4	3GJP202430-A_G	3GJP202430-B_G
55	M3JP225SMD	4	3GJP222240-A_G	3GJP222240-B_G
62	M3JP225SME	4	3GJP222250-A_G	3GJP222250-B_G
75	M3JP250SMB	4	3GJP252220-A_G	3GJP252220-B_G
86	M3JP250SMC	4	3GJP252230-A_G	3GJP252230-B_G
110	M3JP280SMC	4	3GJP282230-A_G	3GJP282230-B_G
1) Kelas efisiensi IE1
1000 putaran/menit = 6 kutub
0,37	M3JP80MA	6	3GJP083310-A_H	3GJP083310-B_H
0,55	M3JP80MB	6	3GJP083320-A_H	3GJP083320-B_H
0,75	M3JP90SLA	6	3GJP093010-A_H	3GJP093010-B_H
1.1	M3JP90SLC	6	3GJP093030-A_H	3GJP093030-B_H
1.5	M3JP100LA	6	3GJP103510-A_H	3GJP103510-B_H
2.2	M3JP112MB	6	3GJP113320-A_H	3GJP113320-B_H
3	M3JP132SMB	6	3GJP133220-A_H	3GJP133220-B_H
4	M3JP132SMC	6	3GJP133230-A_H	3GJP133230-B_H
5.5	M3JP132SMD	6	3GJP133240-A_H	3GJP133240-B_H
7.5	M3JP160MLA	6	3GJP163410-A_H	3GJP163410-B_H
11	M3JP160MLB	6	3GJP163420-A_H	3GJP163420-B_H
15	M3JP180MLB	6	3GJP183420-A_H	3GJP183420-B_H
18.5	M3JP200MLA	6	3GJP203410-A_G	3GJP203410-B_G
22	M3JP200MLB	6	3GJP203420-A_G	3GJP203420-B_G
30	M3JP225SMB	6	3GJP223220-A_G	3GJP223220-B_G
37	M3JP250SMA	6	3GJP253210-A_G	3GJP253210-B_G
45	M3JP280SMA	6	3GJP283210-A_G	3GJP283210-B_G
55	M3JP280SMB	6	3GJP283220-A_G	3GJP283220-B_G
75	M3JP315SMA	6	3GJP313210-A_G	3GJP313210-B_G
90	M3JP315SMB	6	3GJP313220-A_G	3GJP313220-B_G
110	M3JP315SMC	6	3GJP313230-A_G	3GJP313230-B_G
132	M3JP315MLA	6	3GJP313410-A_G	3GJP313410-B_G
160	M3JP355SMA	6	3GJP353210-A_G	3GJP353210-B_G
200	M3JP355SMB	6	3GJP353220-A_G	3GJP353220-B_G
250	M3JP355SMC	6	3GJP353230-A_G	3GJP353230-B_G
315	M3JP355MLB	6	3GJP353420-A_G	3GJP353420-B_G
355	M3JP355LKA	6	3GJP353810-A_G	3GJP353810-B_G
400	M3JP400LKA	6	3GJP403810-A_G	3GJP403810-B_G
400	M3JP400LA	6	3GJP403510-A_G	3GJP403510-B_G
450	M3JP400LKB	6	3GJP403820-A_G	3GJP403820-B_G
450	M3JP400LB	6	3GJP403520-A_G	3GJP403520-B_G
500	M3JP400LKC	6	3GJP403830-A_G	3GJP403830-B_G
500	M3JP400LC	6	3GJP403530-A_G	3GJP403530-B_G
560	M3JP400LD	6	3GJP403540-A_G	3GJP403540-B_G
560	M3JP400LKD	6	3GJP403840-A_G	3GJP403840-B_G
610	M3JP450LA	6	3GJP453510-A_G	3GJP453510-B_G
1000 putaran/menit = 6 kutub
14	M3JP160MLC	6	3GJP163430-A_H	3GJP163430-B_H
18.5	M3JP180MLC	6	3GJP183430-A_H	3GJP183430-B_H
30	M3JP200MLC	6	3GJP203430-A_G	3GJP203430-B_G
37	M3JP225SMC	6	3GJP223230-A_G	3GJP223230-B_G
45	M3JP250SMB	6	3GJP253220-A_G	3GJP253220-B_G
75	M3JP280SMC	6	3GJP283230-A_G	3GJP283230-B_G
1) Kelas efisiensi IE1
750 putaran/menit = 8 kutub
0,18	M3JP80MA	8	3GJP084310-A_H	3GJP084310-B_H
0,25	M3JP80MB	8	3GJP084320-A_H	3GJP084320-B_H
0,37	M3JP90SLA	8	3GJP094010-A_H	3GJP094010-B_H
0,55	M3JP90SLC	8	3GJP094030-A_H	3GJP094030-B_H
0,75	M3JP100LA	8	3GJP104510-A_H	3GJP104510-B_H
1.1	M3JP100LB	8	3GJP104520-A_H	3GJP104520-B_H
1.5	M3JP112MC	8	3GJP114330-A_H	3GJP114330-B_H
2.2	M3JP132SMC	8	3GJP134230-A_H	3GJP134230-B_H
3	M3JP132SMD	8	3GJP134240-A_H	3GJP134240-B_H
4	M3JP160MLA	8	3GJP164410-A_H	3GJP164410-B_H
5.5	M3JP160MLB	8	3GJP164420-A_H	3GJP164420-B_H
7.5	M3JP160MLC	8	3GJP164430-A_H	3GJP164430-B_H
11	M3JP180MLB	8	3GJP184420-A_H	3GJP184420-B_H
15	M3JP200MLA	8	3GJP204410-A_G	3GJP204410-B_G
18.5	M3JP225SMA	8	3GJP224210-A_G	3GJP224210-B_G
22	M3JP225SMB	8	3GJP224220-A_G	3GJP224220-B_G
30	M3JP250SMA	8	3GJP254210-A_G	3GJP254210-B_G
37	M3JP280SMA	8	3GJP284210-A_G	3GJP284210-B_G
45	M3JP280SMB	8	3GJP284220-A_G	3GJP284220-B_G
55	M3JP315SMA	8	3GJP314210-A_G	3GJP314210-B_G
75	M3JP315SMB	8	3GJP314220-A_G	3GJP314220-B_G
90	M3JP315SMC	8	3GJP314230-A_G	3GJP314230-B_G
110	M3JP315MLA	8	3GJP314410-A_G	3GJP314410-B_G
132	M3JP355SMA	8	3GJP354210-A_G	3GJP354210-B_G
160	M3JP355SMB	8	3GJP354220-A_G	3GJP354220-B_G
200	M3JP355SMC	8	3GJP354230-A_G	3GJP354230-B_G
250	M3JP355MLB	8	3GJP354420-A_G	3GJP354420-B_G
315	M3JP400LKA	8	3GJP404810-A_G	3GJP404810-B_G
315	M3JP400LA	8	3GJP404510-A_G	3GJP404510-B_G
355	M3JP400LKB	8	3GJP404820-A_G	3GJP404820-B_G
355	M3JP400LB	8	3GJP404520-A_G	3GJP404520-B_G
400	M3JP400LKC	8	3GJP404830-A_G	3GJP404830-B_G
400	M3JP400LC	8	3GJP404530-A_G	3GJP404530-B_G
430	M3JP450LA	8	3GJP454510-A_G	3GJP454510-B_G
470	M3JP450LB	8	3GJP454520-A_G	3GJP454520-B_G
530	M3JP450LC	8	3GJP454530-A_G	3GJP454530-B_G
600	M3JP450LD	8	3GJP454540-A_G	3GJP454540-B_G
750 putaran/menit = 8 kutub
18.5	M3JP200MLB	8	3GJP204420-A_G	3GJP204420-B_G
30	M3JP225SMC	8	3GJP224230-A_G	3GJP224230-B_G
37	M3JP250SMB	8	3GJP254220-A_G	3GJP254220-B_G
55	M3JP280SMC	8	3GJP284230-A_G	3GJP284230-B_G
600 putaran/menit = 10 kutub
3	M3JP160MLA	10	3GJP165410-A_H	3GJP165410-B_H
4	M3JP160MLB	10	3GJP165420-A_H	3GJP165420-B_H
5.5	M3JP160MLC	10	3GJP165430-A_H	3GJP165430-B_H
7.5	M3JP180MLB	10	3GJP185420-A_H	3GJP185420-B_H
11	M3JP200MLA	10	3GJP205410-A_G	3GJP205410-B_G
15	M3JP200MLB	10	3GJP205420-A_G	3GJP205420-B_G
18.5	M3JP225SMB	10	3GJP225220-A_G	3GJP225220-B_G
22	M3JP225SMC	10	3GJP225230-A_G	3GJP225230-B_G
30	M3JP250SMB	10	3GJP255220-A_G	3GJP255220-B_G
37	M3JP280SMB	10	3GJP285220-A_G	3GJP285220-B_G
45	M3JP280SMC	10	3GJP285230-A_G	3GJP285230-B_G
55	M3JP315SMB	10	3GJP315220-A_G	3GJP315220-B_G
75	M3JP315SMC	10	3GJP315230-A_G	3GJP315230-B_G
90	M3JP315MLA	10	3GJP315410-A_G	3GJP315410-B_G
110	M3JP355SMA	10	3GJP355210-A_G	3GJP355210-B_G
132	M3JP355SMB	10	3GJP355220-A_G	3GJP355220-B_G
160	M3JP355SMC	10	3GJP355230-A_G	3GJP355230-B_G
200	M3JP355MLB	10	3GJP355420-A_G	3GJP355420-B_G
250	M3JP400LB	10	3GJP405520-A_G	3GJP405520-B_G
250	M3JP400LKB	10	3GJP405820-A_G	3GJP405820-B_G
315	M3JP400LKC	10	3GJP405830-A_G	3GJP405830-B_G
315	M3JP400LC	10	3GJP405530-A_G	3GJP405530-B_G
355	M3JP450LB	10	3GJP455520-A_G	3GJP455520-B_G
400	M3JP450LC	10	3GJP455530-A_G	3GJP455530-B_G
450	M3JP450LD	10	3GJP455540-A_G	3GJP455540-B_G
500 putaran/menit = 12 kutub
2.2	M3JP160MLB	12	3GJP166420-A_H	3GJP166420-B_H
3	M3JP160MLC	12	3GJP166430-A_H	3GJP166430-B_H
4	M3JP160MLD	12	3GJP166440-A_H	3GJP166440-B_H
5.5	M3JP180MLB	12	3GJP186420-A_H	3GJP186420-B_H
30	M3JP280SMB	12	3GJP286220-A_G	3GJP286220-B_G
37	M3JP280SMC	12	3GJP286230-A_G	3GJP286230-B_G
45	M3JP315SMB	12	3GJP316220-A_G	3GJP316220-B_G
55	M3JP315SMC	12	3GJP316230-A_G	3GJP316230-B_G
75	M3JP315MLA	12	3GJP316410-A_G	3GJP316410-B_G
90	M3JP355SMA	12	3GJP356210-A_G	3GJP356210-B_G
110	M3JP355SMB	12	3GJP356220-A_G	3GJP356220-B_G
132	M3JP355SMC	12	3GJP356230-A_G	3GJP356230-B_G
160	M3JP355MLB	12	3GJP356420-A_G	3GJP356420-B_G
200	M3JP400LKB	12	3GJP406820-A_G	3GJP406820-B_G
200	M3JP400LB	12	3GJP406520-A_G	3GJP406520-B_G
250	M3JP400LC	12	3GJP406530-A_G	3GJP406530-B_G
250	M3JP400LKC	12	3GJP406830-A_G	3GJP406830-B_G
315	M3JP450LC	12	3GJP456530-A_G	3GJP456530-B_G
355	M3JP450LD	12	3GJP456540-A_G	3GJP456540-B_G

Fitur:

Nama Produk: Motor Listrik 3 Fasa
Fitur Perlindungan: Tahan Air, IP55
Lampiran: NEMA
Tipe: Motor Kebisingan Rendah
Fase: 3
Frekuensi: 50Hz/60Hz

Motor Induksi kami dirancang untuk memenuhi kebutuhan Anda sebagai Supplier Motor Listrik. Kami dengan bangga menawarkan model PSTX210 sebagai pilihan untuk kebutuhan Motor Listrik 3 Phase Anda.

Aplikasi:

Motor listrik ABB M2QA QABP QAEJ dan MQAEJ M2QA cocok untuk berbagai aplikasi dan skenario. Motor listrik ini ideal digunakan pada peralatan industri seperti pompa, kipas angin, kompresor, konveyor, dan masih banyak lagi lainnya. Motor listrik dirancang untuk memberikan kinerja dan keandalan luar biasa dalam lingkungan industri yang menuntut.

Motor listrik M2QA dari ABB tersedia dalam pilihan pemasangan di kaki dan pemasangan di flensa, sehingga mudah dipasang dan digunakan. Motor listrik ini memiliki torsi keluaran 200NM dan dilengkapi dengan insulasi kelas F. Motor listrik tersebut memiliki rentang tegangan 220V-480V sehingga cocok digunakan dalam berbagai aplikasi industri.

Jika Anda sedang mencari supplier motor listrik, ABB merupakan brand terpercaya yang menawarkan rangkaian motor listrik berkualitas seperti seri M2QA dan motor ABB M3BP. Motor listrik ini dirancang untuk memberikan kinerja, keandalan, dan efisiensi luar biasa dalam berbagai aplikasi industri.

Kesimpulannya, motor listrik ABB M2QA QABP QAEJ dan MQAEJ M2QA merupakan solusi ideal untuk berbagai aplikasi industri. Motor listrik ini sangat efisien, andal, dan mudah dipasang, menjadikannya sangat cocok untuk lingkungan industri yang menuntut. Hubungi pemasok motor listrik Anda untuk mempelajari lebih lanjut tentang seri ABB M2QA dan motor listrik ABB lainnya seperti motor ABB M3BP.

Tag:

Electric Valve Actuator

Katup Power Station

Elektronik kontrol Relay

ESP Controller

Kinerja tinggi sistem pengapian

Indikator digital kecepatan

Sensor kecepatan rotasi

Cadangan batubara Feeder

3 Fase motor listrik

Berat Feeder Controller

Pengukur Level magnetik

Transformator perlindungan Relay

DC Contactor

Perangkat perlindungan tegangan rendah

Rem hidrolik Thruster elektro

IGBT Power modul

Electric Valve Actuator

Katup Power Station

Elektronik kontrol Relay

ESP Controller

Kinerja tinggi sistem pengapian

Indikator digital kecepatan

Sensor kecepatan rotasi

Cadangan batubara Feeder

3 Fase motor listrik

Berat Feeder Controller

Pengukur Level magnetik

Transformator perlindungan Relay

DC Contactor

Perangkat perlindungan tegangan rendah

Rem hidrolik Thruster elektro

IGBT Power modul

rincian produk

Motor ABB 3GBP seri 3GJP181410-A_H Profesional IP55 3 Fase Motor Listrik

Motor ABB 3GBP seri 3GJP181410-A_H Profesional IP55 3 Fase Motor Listrik

3GBP seri 3 Fase Motor Listrik

IP55 Motor Listrik 3 Fase

Mesin listrik 3 fase profesional

Deskripsi Produk:

Fitur:

Aplikasi:
