ALLEN BRADLEY SLC500 CAT# 1747-L514 SER B PROCESSOR Controller

Name: ALLEN BRADLEY SLC500 CAT# 1747-L514 SER B PROCESSOR Controller
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: 1747-L514
Price: 210.00 USD
Availability: InStock

Nama merek:	AB
Nomor Model:	1747-L514
MOQ:	1
harga:	Dapat dinegosiasikan
Ketentuan Pembayaran:	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Kemampuan Penyediaan:	Di dalam stok

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Amerika Serikat

Sertifikasi:

Kemasan rincian:

Kotak Asli Baru

Menyediakan kemampuan:

Di dalam stok

Menyoroti:

SLC500 SER B Controller

1747-L514 SLC500 Controller

Deskripsi Produk

Detailed Product Description

Brand:	AB	Type:	PLC Processor Controller
Model:	1747-L514	Origin Of Country:	USA
User Memory::	4,000 Instructions	Module Type::	SLC 5/01 Processor
Warranty:	1 Year
Highlight:	ethernet plc controllers , industrial automation using plc

ALLEN BRADLEY SLC500 CAT# 1747-L514 SER B PROCESSOR Controller

Quick Details:

ALLEN BRADLEY
1747-L514
1747L514
DISCONTINUED BY MANUFACTURER
CPU MODULE
4K RAM MEMORY
DH-485
SLC5/01
AVAILABLE
New one with one year warranty and used one with six months warranty
Weight: 1.07 lbs

Description:

The AB 1747-L514 is a SLC 500 SLC 5/01 Processor. This SLC 5/01 Processor has 960 Maximum I/O points and 480 Analog I/O

points with a User Memory of 4,000 Instructions.

About 1747-L514:

The 1747-L514 SLC 5/01 Modular Processor by AB is a modular processor of the SLC 500 system which offers 4K of processor memory, a maximum configuration capacity of 3 Chassis with a total of 30 slots, and an I/O connection capacity range from 4-3940 I/O points. The module has a backplane current of 90mA at 5.0V DC which gets to 0mA at 24V DC and it uses the 1747-BA lithium battery assembly with a 30-minute capacitor life and a lithium battery with a 2-year lifespan for backup power for the standard RAM. The 1747-L514 offers optional EEPROM backup, and with a 4K memory, it can process a maximum of 52 programming instructions, using the RSLogix 500 programming software.

The 1747-L514 has a maximum bit execution time of 4μs and an overall module scan time of 8ms/K. During a temporary power loss, the program scan on the module can take from 20ms to 3s depending on the power supply that is loading. It comes with a base DH-485 communication capability which can only act in a slave capacity (Receiving) in the programming channel. The 1747-L514 has an ambient operating temperature range of 0-60°C (32-140°F) at 5-95% non-condensing relative humidity range, and it is designed to sustain an operational shock of 30G, and a vibration of 2.5G at 57-2000Hz. The 1747-L514 is C-UL, UL, and CE-certified, and it offers a NEMA standard ICS 2-230 industrial noise immunity.

Technical specifications:

Manufacturer:	Rockwell Automation
Part Number:	1747-L514
Series:	SLC 500
Module Type:	SLC 5/01 Processor
I/O:	960 Maximum
Analog I/O:	480
User Memory:	4,000 Instructions
Program Scan Time:	8 milliseconds

I/O Scan time:	2.6 milliseconds
I/O Chassis:	3
Chassis Module Slots:	30
Communication:	DH-485
Backup Memory:	EEPROM
Backplane Current (5 Volts DC):	350 milliamps
Backplane Current (24 Volts DC):	105 milliamps
Operating Temperature:	0-60 Celsius
