Ge Fanuc Ic693cpu313 ， Embedded Cpu ， Programming Software ， 5-Slotted

Nama merek:	GE
Nomor Model:	IC693CPU311
MOQ:	1
harga:	Negotiations

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Amerika Serikat

Seri:

Seri 90-30

Jenis produk:

Backplane dengan CPU tertanam

Jenis prosesor:

prosesor 80188

Kecepatan prosesor:

10 Megahertz

Jumlah Slot Modul:

Jumlah Port Komunikasi:

Kemasan rincian:

Kotak asli baru

Menyoroti:

Ge Fanuc IC693CPU313 embedded CPU

Ge Fanuc programming software

5-slotted ESP controller

Deskripsi Produk

GE Fanuc IC693CPU313 - Embedded CPU with Programming Software (5-Slotted)

The GE Fanuc IC693CPU313 is an embedded CPU with a 5-slotted baseplate that contains single baseplate per system. This module reaches a processing speed of 10 MHz with the processor 80188.

Key Specifications

Processor	80188 at 10 MHz
Power Requirements	5 VDC, 430 mA
Operating Temperature	0°C to 60°C (32°F to 140°F)
Scan Rate	0.6 milliseconds/1K
Communication Port	1 built-in port (SNP slave and SNP-X slave protocols)

Memory Configuration

Total User Memory: 12 KB for programming
Analog Input (%AI): 64 words
Analog Output (%AO): 32 words
System Status Reference: 128 bits (32 bits per sub-memory type)
System Registers (%SR): 16 words
Data Storage: Up to 1024 words
Internal Coils (%M): 1024 bits
Temporary Output Coils (%T): 264 bits
Discrete Global Memory (%G): 1280 bits

System Features

5-slotted baseplate (plus 1 slot for power supplies)
Compatible with remote and expansion baseplates in Series 90-30 PLC
LAN communication supporting multidrop configuration
Supports optional modules: GCM, GCM+, Ethernet, Profibus, FIP, GBC
Memory storage options: RAM or EPROM
Does not support floating point math
Cannot connect to PCM and CCM devices

Technical Notes

The IC693CPU313 is part of the GE Fanuc Series 90-30 line, featuring a CPU backplane with the CPU module embedded directly into it. This turbo CPU module is designed for industrial automation applications requiring reliable performance in standard operating conditions.

Tag:

lectronics kontrol stabilitas

Ge Fanuc IC693CPU313 embedded CPU

Ge Fanuc programming software
