Hua Heng HY-3VET Vibration Protection System with Amplitude & Intensity Monitoring

Name: Hua Heng HY-3VET Vibration Protection System with Amplitude & Intensity Monitoring
Brand: OUTER ELECTRONIC TECHNOLOGY (HK) LIMITED
SKU: HY-3VET
Price: 210.00 USD
Availability: InStock

Nama merek:	Hua Heng
Nomor Model:	HY-3VET
MOQ:	1
harga:	Dapat dinegosiasikan

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Cina

Kemasan rincian:

Kotak asli baru

Menyoroti:

4.3-inch TFT LCD Touch Screen Vibration Protection System

RS485 Communication Interface Electronic Control Relay

Wide Voltage Input Range Vibration Monitor

Deskripsi Produk

Hua Heng HY-3VET Vibration Protection System

Advanced vibration monitoring system with amplitude and intensity measurement capabilities for industrial protection applications.

Key Features

Advanced embedded chips with digital processing technology for high measurement accuracy and data reliability
Comprehensive anti-interference processing for stable performance in challenging industrial environments
Multiple fault detection functions with alarm and output lock capabilities to prevent false triggers
Wide voltage input range (AC85V-265V or DC100V-360V) for global compatibility
Multiple output options including switch signals, current output, TDM, and RS485 communication with Modbus RTU protocol
4.3-inch TFT color LCD touchscreen with intuitive Chinese/English interface

Technical Specifications

Measurement Range	Amplitude: 0-1000 μm (peak to peak) Intensity: 0-1000 mm/s (true effective value)
Frequency Range	5-3000 Hz
Input Signal	VS series vibration speed sensors (absolute vibration) ES series eddy current sensors (relative shaft vibration)
Measurement Accuracy	Level 0.5, linear error ≤ ±0.5%
Display	4.3-inch TFT true color touch screen
Output Signals	4-20mA current output (load ≤850Ω) BUF signal for waveform analysis RS485 Modbus RTU communication Switch outputs: DC30V/5A or AC250V/5A
Operating Environment	-40℃ to 65℃, relative humidity ≤95% (non-condensing)
Power Supply	AC 85V-265V or DC 100V-360V
