Schneider Electric Quantum Modicon PLC 140SHS94500 New Original

Name: Schneider Electric Quantum Modicon PLC 140SHS94500 New Original
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: 140SHS94500
Price: 210.00 USD
Availability: InStock

Nama merek:	Schneider
Nomor Model:	140SHS94500
MOQ:	1
harga:	Negotiations

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Place of Origin:

France

Type:

QUANTUM PROCESSOR

Packaging Details:

New original box

Menyoroti:

Schneider Electric Quantum Modicon PLC

Modicon PLC 140SHS94500 original

Low Voltage Protection PLC with warranty

Deskripsi Produk

Schneider Electric Quantum Modicon PLC 140SHS94500 New Original

Product Specifications

Attribute	Value
Type	QUANTUM PROCESSOR

Technical Details

Main range of product

Modicon Quantum automation platform

Product or component type

DIO head-end adaptor

Complementary number of port

1 Modbus Plus fiber optic single copper
1 Modbus RS232 twisted pair

Transmission rate

1 Mbit/s

Electrical connection

1 connector RJ45
2 connectors TX/RX

I/O words

30 I/32 O

Checks

RAM
RAM address
Processor
Checksum

Power dissipation

4 W

Minimum pulse width distortion/jitter

5 ns

Wavelength

820 nm

Power loss budget

11 dB 62.5/125 µm
16.5 dB 100/140 µm
6.5 dB 50/125 µm

Optical transmission

-16…-9 dBm 100/140 µm
-19.8…-12.8 dBm 50/125 µm
-3.5…110.5 dBm 62.5/125 µm

Rise/fall time

20 ns

Dynamic range

20 dB

Detected silence

-36 dBm

Sensitivity scale

> 30 dBm

Bus current requirement

750 mA

Environmental Specifications

Resistance to electrostatic discharge

4 kV contact conforming to IEC 801-2
8 kV on air conforming to IEC 801-2

Resistance to electromagnetic fields

10 V/m 80…2000 MHz conforming to IEC 801-3

Ambient air temperature for operation

0…60 °C

Ambient air temperature for storage

-40…85 °C

Relative humidity

95 % without condensation

Operating altitude

<= 5000 m

Standards & Certifications

Standards

UL 508

Product certifications

CSA Class 1 Division 2 RINA GL RMRS C-Tick GOST DNV

Sustainability Information

Offer Sustainability

Green Premium product

REACh Regulation

REACh Declaration

EU RoHS Directive

Pro-active compliance (Product out of EU RoHS legal scope)
EU RoHS Declaration

Mercury free

Yes

RoHS exemption information

Yes

China RoHS Regulation

China RoHS declaration

Environmental Disclosure

Product Environmental Profile

Circularity Profile

End of Life Information

WEEE

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins

Similar Model Products

Analog I/O modules

140ACI03000

140ACI04000

140ACO02000

140ACO13000

140AII33000

140AII33010

140AIO33000

140AMM09000

140ARI03010

140ATI03000

140AVI03000

140AVO02000

Discrete I/O modules

140DDI15310

140DDI35300

140DDI35310

140DDI36400

140DDI67300

140DDI84100

140DDI85300

140DAI34000

140DAI35300

140DAI45300

140DAI54000

140DAI54300

140DAI55300

140DAI74000

140DAI75300

140DSI35300

140DDO15310

140DDO35300

140DDO35301

140DDO35310

140DDO36400

140DDO84300

140DDO88500

140DAO84000

140DAO84010

140DAO84210

140DAO84220

140DAO85300

140DRA84000

140DRC83000

140DVO85300

140DDM39000

140DDM69000

140DAM59000

140DII33000

140DIO33000

(1) CPUs updated with the Unity Pro firmware.

(2) The addition of a complete Ethernet RIO drop function is available for these CPUs with Unity Pro u V7.0.
