Schneider Electric TSX3722001 Modicon TSX Micro automation platform

Name: Schneider Electric TSX3722001 Modicon TSX Micro automation platform
Brand: Hontai Machinery and equipment (HK) Co. ltd
SKU: TSX3722001
Price: 210.00 USD
Availability: InStock

Nama merek:	Schneider
Nomor Model:	TSX3722001
MOQ:	1
harga:	Negotiations

Informasi Rinci

Deskripsi Produk

Informasi Rinci

Tempat asal:

Perancis

Arus keluaran:

0,5A

Kemasan rincian:

Kotak asli baru

Menyoroti:

Modicon TSX Micro automation controller

Schneider Electric automation platform

low voltage protection automation device

Deskripsi Produk

Schneider Electric TSX3722001 Modicon TSX Micro Automation Platform

Key Specifications

Attribute	Value
Output Current	0.5A

Product Description

Schneider Electric TSX3722001 TSX Micro 37 21 22 PLC configurations.

Main Range of Product

Modicon TSX Micro automation platform

Product Type

Modular base controller

Primary Voltage

100...240 V 90…264 V AC

Input Current

2 mA 60 A

Immunity to Microbreaks

20 ms

Output Current

0.5 A

Complementary Slots

Technical Specifications

Analogue Input Type

0...10 V 8

Analogue Output Type

0...10 V 1

Counting Input Type

Discrete incremental counter 1 10 Hz
Incremental 1 10 Hz

Integrated Connection Type

1 serial link (TER/AUX) Uni-Telway 19.2 kbit/s
1 Modbus Modbus RTU 19.2 kbit/s

Realtime Clock

With

Memory Description

Flash 15 Kwords data
Internal RAM 20 Kwords data
Internal RAM (with PCMCIA card) 128 Kwords program and data
Internal RAM 128 Kwords data storage

Performance Specifications

Execution Time per Instruction

0.13 µs Boolean without PCMCIA card
4.5 µs arithmetic REAL floating without PCMCIA card
0.19 µs Boolean with PCMCIA card
4.5 µs arithmetic REAL floating with PCMCIA card

Environmental Specifications

Operating Temperature

0…60 °C

Storage Temperature

-25…70 °C

Relative Humidity

10…95% without condensation for operation
5…95% without condensation for operation

Operating Altitude

0...2000 m

Compliance Information

REACh Regulation

REACh Declaration

EU RoHS Directive

Not applicable, out of EU RoHS legal scope

China RoHS Regulation

China RoHS declaration

WEEE

The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins
